PMA-04AI-I 4-channel analog input module (0/4-20mA)

Picture Name

Classification:

PMA series

PMA-04AI-I is an 8-channel analog input module (current type) used to collect analog signals from industrial sites and process them in the controller

Communication mode:

Click to consult
Add to comparison
Product inquiry
Product Details Technical parameters Download

Close
  • 产品对比
Total X Clear all

Contrast

Basic parameters

Number of channels

4

Bit width in process image

Input 8 * 2 bytes

Configuration method

Automatic configuration in sequence

Connection method

Pluggable

Temperature coefficient

50PPM/K

Range range

0-27648

Resolution ratio

16 位

Accuracy

±0.1%

Connection

Tablet pressing type

Isolation and withstand voltage

500V on site and digital sides, no isolation between channels

Seismic/impact resistance performance

EN 60068-2-6/EN 60068-2-27/29

Data in

Input Current

4~20mA、0~20mA

Input filter

3ms

Impedance

About 100 Ω
